30W 640*480 Fixed focus with BF20A6 1/10 inch CMOS sensor USB interface 30FPS for Video conference phone equipment

Brand Name : Sinoseen

Model Number : SNS-DZ1140-V1.0

Certification : RoHS

Place of Origin : Shenzhen,China

MOQ : 3

Price : negotiable

Payment Terms : T/T

Supply Ability : 500000 pieces/month

Delivery Time : 2-3weeks

Packaging Details : Tray+Anti-static bag in carton box

Type : USB Camera Module

Sensor : BF20A6 1/10 inch

Resolution : 30W 640*480

Dimensions : Customizable

Frame Rate : 30FPS

Lens FOV : 51°

Interface : USB

Contact Now

30W 640*480 Fixed focus with BF20A6 1/10 inch CMOS sensor USB interface 30FPS for Video conference phone equipment

This camera module is a compact and versatile solution for video conferencing applications. It features a 1/10 inch CMOS sensor with a resolution of 640x480 pixels and can capture video at 30 frames per second. The fixed focus lens provides a simple and reliable imaging solution without the need for a complex autofocus machine, and the camera module has a USB interface for easy integration into a variety of video conferencing systems and devices. It is ideal for use in video conferencing phone equipment, providing high-quality video capture capabilities in a compact and cost-effective package.

The BF20A6 CMOS sensor used in this module has good low-light performance and sensitivity, making it suitable for a variety of lighting conditions. The 30W power consumption of this module also makes it an energy-efficient choice for video conferencing applications.

Overall, this 30W 640*480 fixed focus camera module with USB interface and 30FPS capture rate is a reliable and practical solution for integrating high-quality video capabilities into video conferencing phone equipment and other similar applications.

Specification

Module

SNS-DZ1140-V1.0

Sensor BF20A6 CMOS
Image sensor size 1/10 inch
Pixel 30W
Most effective pixels 640*480
Pixel Size 2.25um*2.25um
Frame rate 30fps
Optical distortion <=15.5%
Image sensor Data output RAW Data 10bits
Focus type Fixed focus
Output interface USB2.0
Video output YUV
Output formats RAW Bayer 10bits
Max S/N ratio TBD
Dynamic TBD
Storage temperature -20°C to 70°C
Operating temperature 0°C to 60°C
Support OS WinXP/Vista/Win7/Win8/Win10
Linux with UVC(above linux-2.6.26)
MAC-OS X 10.4.8 or later
Android 4.0 or above with UVC
