Global Exposure 120FPS OV7251 USB Camera Module For Machine Vision Inspection

  • 1
  • 2
  • 3

Brand Name : Sinoseen

Model Number : SNS-GB3403-V1.0

Certification : RoHS

Place of Origin : Shenzhen,China

MOQ : 3

Price : negotiable

Payment Terms : T/T

Supply Ability : 500000 pieces/month

Delivery Time : 2-3weeks

Packaging Details : Tray+Anti-static bag in carton box

Type : USB camera module

Sensor : 1/7.5" Omnivision OV7251

Resolution : 0.3MP 640(H) x 480(V)

Dimensions : 38mmx38mm (customizable)

Lens FOV : 90°(optional)

Focus Type : Fixed focus

Interface : USB2.0

Feature : Global shutter

Contact Now

Global Exposure 120FPS OV7251 USB Camera Module For Machine Vision Inspection​


global shutter usb Camera Module
This camera module is equipped with OV7251 sensor. The sensor offers high sensitivity and excellent image quality for precise inspection and detection of fine details in machine vision applications. The camera module uses global exposure technology that allows all pixels in the image sensor to be exposed simultaneously. This eliminates the rolling shutter effect and ensures accurate capture of fast-moving objects without distortion, making it suitable for machine vision applications where precise timing is critical.


Specification

Model No

SNS-GB3403-V1.0

Sensor

1/7.5’’ Omnivision OV7251

Pixel

0.3 Mega Pixel

Most effective pixels

640(H) x 480(V), 320(H) x 240(V)

Pixel Size

3.0µm x 3.0µm

Image area

1968um(H) x 1488um (V)

Compression format

MJPG

Resolution & Frame rate

640x480 @ 120 fps
320x240@ 120fps
320x120 @ 120fps

Shutter Type

Global Shutter

CFA (Chroma)

Mono, Black/White

Focus type

Fixed focus

S/N ratio

38dB

Dynamic range

69.6dB

Sensitivity

10800mV / lux-sec

Interface type

USB2.0 high speed

Adjustable parameter

Brightness/Contrast/Color saturation/Hue/Definition//White balance

Lens

Focal length: 3.6mm

Lens Size: 1/4 inch

FOV: 90°

Thread Size: M12*P0.5

Audio frequency

Optional

Power supply

USB BUS POWER

Power consumption

DC 5V, 120mW

Main chip

DSP/SENSOR/FLASH

Auto Exposure Control (AEC)

Support

Auto White Balance (AEB)

Support

Auto Gain Control (AGC)

Support

Dimension

38mm*38mm (customizable)

Storage temperature

-30°C to 70°C

Operating temperature

0°C to 60°C

USB cable length

Default

Support OS

WinXP/Vista/Win7/Win8/Win10
Linux with UVC(above linux-2.6.26)
MAC-OS X 10.4.8 or later
Android 4.0 or above with UVC

Global Exposure 120FPS OV7251 USB Camera Module For Machine Vision InspectionGlobal Exposure 120FPS OV7251 USB Camera Module For Machine Vision Inspection


Shenzhen Sinoseen Technology Co.,Ltd
China top 10 camera module manufacturer
We customize all kinds of USB/MIPI/DVP camera module as per your request


Current available global shutter USB camera module


Omnivision OV7251 0.3MP Monochrome(black and white)

Omnivision OV9281 1MP Monochrome(black and white)

ON Semiconductor AR0144 1MP Monochrome(black and white) or RGB color

Omnivision OG02B1B 2MP Monochrome(black and white)

Omnivision OG02B10 2MP RGB color
